求助！
投稿进行到最后一步了
不管是HTML proof 还是PDF proof打开之后都不显示图片，显示一个大叉，请问有筒子碰到过这种情况吗？
是不是格式不对？我用的都是600分辨率的tif格式的，大部分杂志都是这个格式呀，我在杂志主页上找到的图片要求也是这样的呀

要求应该是下面这一段
4.12. Figures and tables

All figures and tables must be referenced in the text and placed in the text near the point of the first mention. Number them consecutively with Arabic numerals. The cap-tions should be understandable without reference to the text. The same data should not be presented in more than one figure or in both a figure and a table. Tables should be created using the table format feature of the MS Word software, and authors should ensure that each data entry is in its own table cell. Schemes are illustrations of chemical structures and reactions, and should be numbered with Arabic numerals in consecutive order. In the initial manuscript submission, the figures and tables must be of sufficient quality for peer review. When the manuscript is accepted, all figures and tables, and their titles and legends may be re-created or edited to accord with the Journal style prior to publication or authors may be asked to provide proper figures (including experimental data) by the production staff.
All graphics (including chemical structures) must be pro-vided at the actual size that they are to appear (sin-gle-column width is 8.4 cm, double-column width is 17.5 cm). Please arrange schematics so that they fill the column space (either single or double), so as not to leave a lot of un-used white space. Please ensure that all illustrations with-in a paper are consistent in type, quality, and size. Legends may be included as part of the graphic for reviewing purposes.
To help authors provide actual size graphics, it is sug-gested that the following settings be used with CSC ChemDraw and ISIS Draw: font 10 pt Times New Roman, chain angle 120°, bond spacing 18% of length, fixed length 14.4 pt (0.508 cm), bold width 2 pt (0.071 cm), line width 0.6 pt (0.021 cm), margin width 1.6 pt (0.056 cm), and hash spacing 2.5 pt (0.088 cm). The original drawing cannot exceed a column width of 8.4 cm (for single column) and 17.5 cm (for double column). And add the Schemes to the main text by copying and pasting. Please save graphics as a file with .cdx extension and submit it together with the main text. It is suggested that the following settings be used with Origin software: font 9 pt Times New Roman, Line Width 0.4, Symbol size 0.3, in Title & Formatchain: Thichness 0.3?Major Tick 3?Major and Minor both In, Ratio 100 in Copy Page Settings in Options. The original drawing cannot exceed a column width of 8.4 cm (for single column) and 17.5 cm (for double column). And add the Schemes to the main text by copying and pasting.
Formats. Regardless of the application used, when your electronic artwork is finalized, please "save as" or convert the images to one of the following formats (note the resolution requirements for line drawings, halftones, and line/halftone combinations given below).
TIFF: the minimum resolution for a black and white line art, grayscale art, and color art is 1200, 600, and 300 dpi, respectively.
TIFF: Combinations bitmapped line/half-tone (color or grayscale) of a minimum of 600 dpi is required.
DOC, XLS or PPT: If your electronic artwork is created in any of these Microsoft Office applications please supply "as is".
